Specification |
Printing |
---|
Type | Mobile printer | Print technology | Direct thermal | Print speed | 6 ips | Print speed | 152 mm/sec | Maximum resolution | 203 x 203 DPI | Performance |
---|
Type | Mobile printer | Print technology | Direct thermal | Print speed | 6 ips | Print speed | 152 mm/sec | Maximum resolution | 203 x 203 DPI | Built-in barcodes | AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1-128, ITF, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E | Paper handling |
---|
Maximum media length | 100 cm | Maximum roll diameter | 6 cm | Maximum printing width | 5.4 cm | Ports & interfaces |
---|
Bluetooth profiles | BIP, HCRP, OPP, SPP | Connectivity technology | Wired & Wireless | USB 2.0 ports quantity | 1 | USB port | Yes | USB connector | Mini-USB Type-B | Mobile printing technologies | Apple AirPrint, Google Cloud Print | Network |
---|
Wi-Fi Direct | Yes | Ethernet LAN | No | Wi-Fi | Yes | Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) | Print technology |
---|
Type | Mobile printer | Print technology | Direct thermal | Print speed | 6 ips | Print speed | 152 mm/sec | Print quality |
---|
Maximum media length | 100 cm | Maximum resolution | 203 x 203 DPI | Maximum printing width | 5.4 cm | Technical details |
---|
Maximum media length | 100 cm | International Protection (IP) code | IP54 | Bluetooth profiles | BIP, HCRP, OPP, SPP | Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64 | Mobile printing technologies | Apple AirPrint, Google Cloud Print | Maximum printing width | 5.4 cm | Product colour | Black, Grey | Built-in barcodes | AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1-128, ITF, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E | Products per pallet | 150 pc(s) | Layers per pallet | 5 pc(s) | Master (outer) cases per pallet | 50 pc(s) | Pallet gross weight | 225 kg | Pallet gross height | 14 cm | Country of origin | China | Master (outer) cases per pallet layer | 10 pc(s) | Harmonized System (HS) code | 84433210 | Pallet type | 800 x 1200 mm | Features |
---|
International Protection (IP) code | IP54 | Mobile printing technologies | Apple AirPrint, Google Cloud Print | RAM capacity | 0.032 GB | Internal memory | 32 MB | Product colour | Black, Grey | Built-in barcodes | AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1-128, ITF, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E | Page description languages | CPCL-native, ESC P, ZPL II | Country of origin | China | Design |
---|
Display diagonal | 6.1 cm (2.4") | Product colour | Black, Grey | Built-in display | Yes | Display | LCD | Display |
---|
Display diagonal | 6.1 cm (2.4") | Built-in display | Yes | Display | LCD | Memory |
---|
RAM capacity | 0.032 GB | Internal memory | 32 MB | Power |
---|
Rechargeable | Yes | Battery type | PA-BT-003 | Power source type | Battery | Battery voltage | 7.2 V | Battery technology | Lithium-Ion (Li-Ion) | Operational conditions |
---|
Storage temperature (T-T) | -25 - 65 °C | Operating temperature (T-T) | -20 - 50 °C | Operating relative humidity (H-H) | 10 - 90% | System requirements |
---|
Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64 | Weight & dimensions |
---|
Width | 125 mm | Depth | 185 mm | Height | 230 mm | Package weight | 1.46 kg | Weight | 957 g | Packaging data |
---|
Package weight | 1.46 kg | Packaging content |
---|
Quick start guide | Yes | AC adapter included | Yes | Drivers included | Yes | Batteries included | Yes | Software |
---|
Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64 | Logistics data |
---|
Products per pallet | 150 pc(s) | Layers per pallet | 5 pc(s) | Master (outer) cases per pallet | 50 pc(s) | Pallet gross weight | 225 kg | Pallet gross height | 14 cm | Harmonized System (HS) code | 84433210 | Other features |
---|
Wi-Fi Direct | Yes | Rechargeable | Yes | International Protection (IP) code | IP54 | Battery type | PA-BT-003 | Mobile printing technologies | Apple AirPrint, Google Cloud Print |
|
