| Specification |
| Print quality |
|---|
| Maximum resolution | 300 x 300 DPI | | Maximum printing width | 5.9 cm | | Printing |
|---|
| Colour | No | | Print speed | 152 mm/sec | | Maximum resolution | 300 x 300 DPI | | Maximum printing width | 5.9 cm | | Print technology | Direct thermal | | Display |
|---|
| Display | LCD | | Network |
|---|
| Wi-Fi | Yes | | Ethernet LAN | Yes | | Memory |
|---|
| Internal memory | 256 MB | | Paper handling |
|---|
| Media thickness | 0.058 - 0.279 mm | | Maximum roll diameter | 12.7 cm | | Maximum label length | 3 m | | Ports & interfaces |
|---|
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) | | USB 2.0 ports quantity | 1 | | RS-232 ports | 1 | | Connectivity technology | Wired & Wireless | | Bluetooth version | 5.2+EDR | | Bluetooth | Yes | | Wi-Fi | Yes | | Ethernet LAN | Yes | | USB port | Yes | | Performance |
|---|
| Mobile operating systems supported | Android, iOS | | Built-in barcodes | AZTECCODE, Data Matrix, MSI, CODABAR (NW-7), UPC-A, MaxiCode, Micro QR Code, UPC-E, EAN13, Code 128 (A/B/C), EAN8, POSTNET, Code 39, GS1 DataBar, QR Code, Code 93 | | Number of fonts | 10 | | Security algorithms | 64-bit WEP, 128-bit WEP, WPA2-PSK, PEAP, EAP-FAST, WPA3-SAE, EAP-TLS, EAP-TTLS, WPA-PSK | | Internal memory | 256 MB | | Page description languages | ESC P, Raster_P | | Design |
|---|
| Display | LCD | | Product colour | Black, Grey | | Control type | Buttons | | Built-in display | Yes | | Power |
|---|
| AC adapter output voltage | 24 V | | AC adapter output current | 3.6 A | | AC input voltage | 100 - 240 V | | AC input frequency | 50/60 Hz | | USB port voltage | 5 V | | USB port current | 3 A | | Power source type | AC | | Technical details |
|---|
| Windows operating systems supported | Windows 10, Windows 11 | | Product colour | Black, Grey | | Built-in barcodes | AZTECCODE, Data Matrix, MSI, CODABAR (NW-7), UPC-A, MaxiCode, Micro QR Code, UPC-E, EAN13, Code 128 (A/B/C), EAN8, POSTNET, Code 39, GS1 DataBar, QR Code, Code 93 | | Number of fonts | 10 | | Maximum label length | 3 m | | Country of origin | Vietnam | | Products per pallet | 60 pc(s) | | Layers per pallet | 5 pc(s) | | Master (outer) cases per pallet | 20 pc(s) | | Warranty period | 3 year(s) | | Pallet type | 800 x 1200 mm | | Security |
|---|
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA2-PSK, PEAP, EAP-FAST, WPA3-SAE, EAP-TLS, EAP-TTLS, WPA-PSK | | System requirements |
|---|
| Mobile operating systems supported | Android, iOS | | Linux operating systems supported | Yes | | Windows operating systems supported | Windows 10, Windows 11 | | Operational conditions |
|---|
| Storage temperature (T-T) | -20 - 60 °C | | Storage relative humidity (H-H) | 10 - 90% | | Operating temperature (T-T) | 5 - 40 °C | | Operating relative humidity (H-H) | 20 - 80% | | Weight & dimensions |
|---|
| Package width | 306 mm | | Package depth | 181 mm | | Package height | 325 mm | | Width | 181 mm | | Depth | 306 mm | | Height | 325 mm | | Weight | 1.62 kg | | Package weight | 2.66 kg | | Packaging data |
|---|
| Package width | 306 mm | | Package depth | 181 mm | | Package height | 325 mm | | Package weight | 2.66 kg | | Packaging content |
|---|
| Cables included | AC, USB | | Other features |
|---|
| Products per pallet | 60 pc(s) | | Layers per pallet | 5 pc(s) | | Master (outer) cases per pallet | 20 pc(s) | | Country of origin | Vietnam | | Warranty period | 3 year(s) | | Spare part retention | 5 year(s) | | Logistics data |
|---|
| Pallet gross height | 17.8 cm | | Master (outer) cases per pallet layer | 4 pc(s) | | Pallet gross weight | 591.6 kg | | Products per pallet | 60 pc(s) | | Layers per pallet | 5 pc(s) | | Master (outer) cases per pallet | 20 pc(s) |
|
