| Specification |
| Print quality |
|---|
| Maximum resolution | 300 x 300 DPI | | Maximum printing width | 10.6 cm | | Printing |
|---|
| Rotated printing | Yes | | Minimum print length | 11.4 m | | Colour | No | | Printing colours | Black | | Print speed | 102 mm/sec | | Maximum resolution | 300 x 300 DPI | | Maximum printing width | 10.6 cm | | Print technology | Direct thermal / Thermal transfer | | Number of printable dots | 12 dot | | Design |
|---|
| LED indicators | Yes | | Housing material | Plastic | | Display diagonal | 5.84 cm (2.3") | | Colour display | Yes | | Display resolution | 320 x 240 pixels | | Display | TFT | | Product colour | Navy | | Built-in display | Yes | | Certification | FCC Class B, CE Class B, C-Tick Class B, UL, cUL, TÜV/safety, CCC, CoC-Mexico | | Display |
|---|
| Display diagonal | 5.84 cm (2.3") | | Colour display | Yes | | Display resolution | 320 x 240 pixels | | Display | TFT | | Network |
|---|
| Wi-Fi | No | | Ethernet LAN | Yes | | Memory |
|---|
| Internal memory | 64 MB | | Flash memory | 128 MB | | Paper handling |
|---|
| Ribbon width | 4 cm | | Ribbon length | 110 m | | Media thickness | 0.06 - 0.19 mm | | Maximum roll diameter | 12.7 cm | | Maximum label width | 10.6 cm | | Maximum label length | 11.4 m | | Core diameter | 3.81 cm | | Core diameters supported | 12.7 mm (0.5") | | Ports & interfaces |
|---|
| USB 2.0 ports quantity | 1 | | RS-232 ports | 1 | | Optional connectivity | Bluetooth, Wireless LAN | | Connectivity technology | Wired | | Bluetooth | No | | Wi-Fi | No | | Ethernet LAN | Yes | | USB port | Yes | | Performance |
|---|
| Clock function | Yes | | Built-in barcodes | Code 93, GS1 DataBar, Plessey, 2D, Code-128 Codabar Library, ITF-14, QR Code, AZTECCODE, Code128UCC, TELEPEN, TELEPENN, Deutsche Post Identcode, MSI, Deutsche Post Leitcode, GS1 DataMatrix, Macro PDF417, Code 11, UPC-A, Code 128 (A/B/C), EAN128, MaxiCode, EAN13, UPC-E, EAN8, PDF417, Code 39, Planet, Code 49, POSTNET | | Number of fonts | 8 | | Ribbon width | 4 cm | | Ribbon length | 110 m | | Internal memory | 64 MB | | Flash memory | 128 MB | | Compatible memory cards | SD | | Built-in processor | Yes | | Certification | FCC Class B, CE Class B, C-Tick Class B, UL, cUL, TÜV/safety, CCC, CoC-Mexico | | Page description languages | TSPL-EZ | | Power |
|---|
| AC adapter output voltage | 2.5 V | | AC adapter output current | 3.75 A | | Power consumption (printing) | 90 W | | AC input voltage | 100- 240 V | | AC input frequency | 50 - 60 Hz | | Technical details |
|---|
| Windows operating systems supported | Yes | | Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave | | Product colour | Navy | | Built-in barcodes | Code 93, GS1 DataBar, Plessey, 2D, Code-128 Codabar Library, ITF-14, QR Code, AZTECCODE, Code128UCC, TELEPEN, TELEPENN, Deutsche Post Identcode, MSI, Deutsche Post Leitcode, GS1 DataMatrix, Macro PDF417, Code 11, UPC-A, Code 128 (A/B/C), EAN128, MaxiCode, EAN13, UPC-E, EAN8, PDF417, Code 39, Planet, Code 49, POSTNET | | Number of fonts | 8 | | Ribbon width | 4 cm | | Ribbon length | 110 m | | Maximum label width | 10.6 cm | | Maximum label length | 11.4 m | | LED indicators | Yes | | Compatible memory cards | SD | | Clock function | Yes | | Sustainability certificates | ENERGY STAR | | Processor |
|---|
| Built-in processor | Yes | | Certificates |
|---|
| Certification | FCC Class B, CE Class B, C-Tick Class B, UL, cUL, TÜV/safety, CCC, CoC-Mexico | | Software |
|---|
| Bundled software | Windows labeling | | System requirements |
|---|
| Linux operating systems supported | Yes | | Windows operating systems supported | Yes | | Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave | | Operational conditions |
|---|
| Storage temperature (T-T) | -40 - 60 °C | | Storage relative humidity (H-H) | 10 - 90% | | Operating temperature (T-T) | 5 - 40 °C | | Operating relative humidity (H-H) | 25 - 85% | | Weight & dimensions |
|---|
| Width | 203 mm | | Depth | 259.3 mm | | Height | 191.5 mm | | Weight | 2.3 kg | | Package type | Box | | Packaging data |
|---|
| Package type | Box | | Quantity per pack | 1 pc(s) | | Packaging content |
|---|
| Quick start guide | Yes | | Cables included | DC | | Bundled software | Windows labeling | | Quantity per pack | 1 pc(s) | | Other features |
|---|
| Quantity per pack | 1 pc(s) | | Clock function | Yes | | LED indicators | Yes |
|
